*Washing machine pump Askoll 3 screw 25 W chip back M116 with volute assembly

Превью запчасти *Washing machine pump Askoll 3 screw 25 W chip back M116 with volute assembly photo 1 -

Code: 15552 | Art: PMP015UN

under the order

Characteristics

Manufacturer

—

Askoll

Country of origin

—

Italy

Power, W

—

Number of latches

—

Connector/terminal position

—

backward

All characteristics

They buy with this product

The drain pump for a washing machine is used to remove water after the wash cycle. The part is supplied assembled with an M116 volute. Power is 25 W, the winding is copper, the mounting type is 3 screws, and the design includes 3 latches. The connection uses a plug positioned at the back; country of manufacture is Italy. Article: PMP015UN, 15552. Alternative article: 44511, 144971, 144617, 145338, 145755, 145777, PMP015BO,TWG000746159,Electrolux 1326630207. Compatible brand: Asko. Spare part compatibility depends on the model and year of manufacture of the appliance — if in doubt, check with a manager.

Product characteristics

Manufacturer	Askoll
Country of origin	Italy
Power, W	25
Number of latches	3
Connector/terminal position	backward
Winding	Copper
Connector type	Connector
Mounting type	3 screws
Alternative article	44511, 144971, 144617, 145338, 145755, 145777, PMP015BO,TWG000746159,Electrolux 1326630207
Источник	интернет-магазин запчастей https://magsbt.com/

Assessment 5, 16 votes

Collections

All spare parts Askoll

Askoll M116 25W drain pump with volute

The Askoll M116 drain pump removes used water from a washing machine. This assembly includes the volute, has 25 W power, 3-screw mounting and a rear-positioned plug connector. The winding is specified as copper.

Suitable for

For replacing the drain unit in washing machines with a matching M116 pump layout. It is relevant when the appliance does not drain properly or the pump assembly is faulty.

Compatible brands and models

Equipment brand: Asko
Equipment brand: 2I MARCHI
Equipment brand: Ariston
Equipment brand: Bosch
Equipment brand: Candy
Equipment brand: Creda
Equipment brand: Gaggenau
Equipment brand: Hotpoint
Equipment brand: Hotpoint-Ariston
Equipment brand: Indesit
Equipment brand: Neff
Equipment brand: SCHOLTES
Equipment brand: Siemens
Equipment brand: Whirlpool
Equipment model: Ariston A1124UK
Equipment model: Ariston A1234UK
Equipment model: Ariston ALDS100EX
Equipment model: Ariston ALS88XEU
Equipment model: Bosch WFF1201/01
Equipment model: Candy Alise 842K
Equipment model: Candy Alise 844
Equipment model: Candy Aquamatic 1000T
Equipment model: Candy Aquamatic 10T
Equipment model: Candy Aquamatic 600
Equipment model: Hotpoint-Ariston RSM601W
Equipment model: Indesit EWD71052HK
Equipment model: Indesit EWSD51031CIS
Equipment model: Indesit IWSB5085CIS
Equipment model: Indesit IWSC5105CIS
Equipment model: Indesit IWUB4085CIS
Equipment model: Indesit IWUB4105CIS

Key specifications

Manufacturer: Askoll; country of manufacture: Italy.
Power: 25 W; winding: copper.
Mounting: 3 screws; connection: plug, positioned at the rear.
Part numbers: PMP015UN, 15552.
Alternative codes: 44511, 144971, 144617, 145338, 145755, 145777, PMP015BO, TWG000746159, Electrolux 1326630207.

Before ordering

Before ordering, check the 3-screw mounting, rear plug position, 25 W power and the M116/volute layout against the removed pump.

Applicability of the product to models of household appliances

Enter the first characters of the model in the search line below and the list will be filtered.
You can click on the model name to search for all spare parts for this model of equipment.

AL89X (IT), AL68X (IT), AB108X (IT), AB88X (IT), AL89XS (IT), ALS109 X (IT), ALS89 XS (IT), ALS89 X (IT), AL68 X (PT), AB54 X (PT), AL108 X (TK), AB63 X (EX), AL88 X (EU), AL109 X (EU), AL129 X (EU), AL149 X (EX), ABS63 X (EU), ALS88 X (EU), ALS109 X (EU), ALS129 X (EU), WS44 X (IT), WS431 TX (EX), WS642 TX (EX), WS84 TX (EX), WS105 TX (EX), W431 TX (EX), W125 TX (EX), W145 TX (EX), W63 X (SP), W84 X (SP), W84 TX (TK), W104 TX (TK), W123 S (UK), W143 X (NL), W124 X (NL), W144 X (NL), A1124 (UK), A1234 (UK), A1435 (UK), A1435 S (UK), AL108 X (BE), AB88 X (EX), AL68 X (EX), AL129 X (AUS), AB53 X (EU), AB65 X (EU), AL64 X (SP), W133 (UK), W128 X (SP), W125 X (FR), WS43 X (IT), WS63 X (IT), WE10 (UK), WE12 (UK), WE12 S (UK), WE13 (UK), WE14 (UK), W84 XS (SP), AB65 X (EO), W133 S (UK), W144 XS (NL), WE12 X (NL), WE14 X (NL), W165 X (NL), WE16 X (NL), WE125 X (EX), WE145 X (EX), W165 TX (EX), W682 X S (IT), W842 X S (IT), WS682 X S (IT), W124 X (DE), W125 X (DE), W125 XS (DE), W126 X (DE), W144 X (DE), W145 X (DE),
