*Washing machine pump Askoll 3 latches 35 W chip back EBS105-015 M301 replacement PMP015WH

*Washing machine pump Askoll 3 latches 35 W chip back EBS105-015 M301 replacement PMP015WH photo 2 -

*Washing machine pump Askoll 3 latches 35 W chip back EBS105-015 M301 replacement PMP015WH photo 3 -

Превью запчасти *Washing machine pump Askoll 3 latches 35 W chip back EBS105-015 M301 replacement PMP015WH photo 3 -

Code: 21510 | Art: IG5422

under the order

Characteristics

Manufacturer

—

Askoll

Country of origin

—

Italy

Power, W

—

Number of latches

—

Connector/terminal position

—

backward

All characteristics

They buy with this product

This drain pump for a washing machine is used in the water drainage system. Key specifications: 35 W power, copper winding, mounting with 3 latches, and a plug connector positioned toward the rear. Articles: IG5422, 21510; country of manufacture — Italy. Compatible brand: Bosch (Бош). Spare part compatibility depends on the appliance model and year of production — if in doubt, check with a manager.

Product characteristics

Manufacturer	Askoll
Country of origin	Italy
Power, W	35
Number of latches	3
Connector/terminal position	backward
Winding	Copper
Connector type	Connector
Mounting type	Locks
Источник	интернет-магазин запчастей https://magsbt.com/

Assessment 5, 22 vote

Collections

All spare parts Askoll

Askoll EBS105-015 M301 35 W Drain Pump

The Askoll EBS105-015 M301 drain pump removes water from the washing machine tub into the drain path. It operates during drain and rinse cycles. This version uses a rear plug connector and 3-latch mounting.

Suitable for

For replacing the drain pump in compatible Bosch washing machines. It is used in the water drain circuit after washing, rinsing and drain cycles.

Compatible brands and models

Equipment brand: Bosch

Key specifications

Manufacturer: Askoll; country of manufacture: Italy.
Model code: EBS105-015 M301; article codes: IG5422, 21510; analog: PMP015WH.
Power: 35 W; winding: copper.
Mounting: 3 latches.
Connection: plug connector, rear position.

Before ordering

Before ordering, check the old pump for 3-latch mounting, rear plug, 35 W rating and code EBS105-015 M301/PMP015WH.

Applicability of the product to models of household appliances

Enter the first characters of the model in the search line below and the list will be filtered.
You can click on the model name to search for all spare parts for this model of equipment.

100 989 30 DWF A00 W 100 989 30 DWF A00 W (854860001720) 300 989 29 DWF A00 S 300 989 29 DWF A00 S (854860001710) 500 989 33 DWF A40 W 500 989 33 DWF A40 W (854864016720) 700 989 32 DWF A40 S 700 989 32 DWF A40 S (854864016710) 900 989 31 DWF A10 S 900 989 31 DWF A10 S (854861015710) ADP 5329 WH ADP 5329 WH (854841101580) ADP 5329 WH (854841101581) ADP 6529 WH ADP 6529 WH (854841101570) ADP 6529 WH (854841101571) ADP 6529 WH (854841101572) ADP 6839 WH STEAM ADP 6839 WH STEAM (854841101560) ADP 6839 WH STEAM (854841101561) DWF A 10 S DWF A 10 S (854861015715) DWF A40 S DWF A40 S (854864016711) DWF A40 W DWF A40 W (854864016721) GSF 100 POWER IN GSF 100 POWER IN (854840422950) GSF 100 POWER IN (854840422951) GSF 100 POWER IN (854840422952) GSF 100 POWER WS GSF 100 POWER WS (854840222960) GSF 100 POWER WS (854840422940) GSF 100 POWER WS (854840422941) GSF 100 POWER WS (854840222961) GSF 100 POWER WS (854840422942) GSF 110 ECO GSF 110 ECO (854840422010) GSF 1546 WS GSF 1546 WS (854840101810) GSF 1546 WS (85484010
