Product characteristics
Manufacturer | Panasonic |
Country of origin | China |
Color | Beige |
Material | Plastic |
Height, mm | 35 |
Number of upper teeth | 14 |
Number of lower teeth | 78 |
Outer diameter, mm | 78.5 |
Inner diameter, mm | 29 |
Inner diameter, mm | 29 |
Tooth direction | Lower angled, upper angled |
Источник | интернет-магазин запчастей https://magsbt.com/ |
Collections
Panasonic meat grinder gear D78.5/29 mm h35 mm z78/14
This beige plastic gear is intended for a Panasonic meat grinder. It works in the gear train and helps transfer rotation between mechanism parts. The design uses angled teeth on both the lower and upper gear sections.
Suitable for
Suitable for repairing the gear transmission of Panasonic meat grinders when the dimensions, seat and tooth count match.
Compatible brands and models
- Equipment brand: Panasonic
Key specifications
- Part number: 00000007619 (051А), 7619; alternative part number: R1609, КХ-0009741
- Outer diameter 78.5 mm, inner diameter 29 mm, height 35 mm
- Tooth count: 78 lower teeth and 14 upper teeth
- Tooth direction: angled lower teeth and angled upper teeth
- Plastic material, beige color, country of manufacture China
Before ordering
Before ordering, check the outer and inner diameters, height, seat, 78/14 tooth count and angled direction of both gear sections.
