*Multimeter digital-pliers VALUE VCM 202

Превью запчасти *Multimeter digital-pliers VALUE VCM 202 photo 1 -

Code: 7103 | Art: VCM202

under the order

Characteristics

Manufacturer

—

Value

Country of origin

—

China

Alternative article

—

VCM202, 1008293.

A digital clamp meter is an electronic tool for measuring electrical circuit parameters. The listed article numbers are VCM202, 7103, and the alternative article numbers are VCM202, 1008293. The country of manufacture is China. The instrument can be used as a clamp multimeter, voltmeter, or current clamp. Suitability depends on the measurement task; if in doubt, consult a manager.

Product characteristics

Manufacturer	Value
Country of origin	China
Alternative article	VCM202, 1008293.
Источник	интернет-магазин запчастей https://magsbt.com/

Assessment 5, 26 votes

Collections

All spare parts Value

VALUE VCM 202 digital clamp multimeter

VALUE VCM 202 is a digital clamp multimeter for measuring parameters of a household electrical network. The clamp jaw is intended for a single-core conductor up to 38 mm in diameter. The device measures AC current, AC voltage, resistance and frequency, and can be used for continuity checks. The kit includes crocodile clips, a case and a 9 V battery.

Suitable for

Used for electrical network diagnostics and service work when cable current, voltage, resistance or frequency needs to be checked.

Key specifications

Manufacturer: Value; country of manufacture: China; part numbers: VCM202, 7103; alternative: VCM202, 1008293.
Clamp jaw: up to 38 mm for a single-core conductor; overload protection: 250 V.
AC current: up to 600 A; ranges 200 A at 0.1 A resolution and 600 A at 1 A resolution.
AC voltage: up to 600 V; resistance: 0–200 Ohm at 0.1 Ohm resolution; frequency: 45 Hz – 2 kHz.
Dimensions without case: 34 × 85 × 208 mm; protection rating: IP30; power: one 9 V Krona battery.

Before ordering

Before ordering, check that the conductor is single-core and no more than 38 mm in diameter, and that the required measurements fit the 600 A and 600 V limits.
