Product characteristics
Country of origin | China |
Alternative article | 100005757; 23172 |
Источник | интернет-магазин запчастей https://magsbt.com/ |
DT-201 clamp multimeter for AC current up to 1000 A
The DT-201 is an entry-level digital clamp multimeter. It is designed for non-contact AC current measurement up to 1000 A without opening the circuit or disconnecting the load. The instrument also measures resistance up to 2 kΩ.
Suitable for
Suitable for checking electrical installations such as motors, generators and machine tools, as well as household wiring and phase conductors in an electrical panel.
Key specifications
- Part numbers: DT-201, 20139; alternatives: 100005757, 23172.
- Maximum CAT II voltage: 1000 V DC or 750 V AC between probes and earth.
- LCD display shows up to 1999 counts; measurement time is 2–3 s.
- Maximum jaw opening is 42 mm.
- Power supply: 9 V Krona battery; overload protection 1200 A for up to 60 s.
Before ordering
Before ordering, check that AC current measurement up to 1000 A is required and that the 42 mm jaw opening fits the conductor.
