Code: 21621 | Art: BH53520A 03
under the order
Characteristics
Manufacturer
—
DIXELL
Country of origin
—
Italy
They buy with this product
Pressure switch DIXELL PPR35S (0:34.5 bar) high pressure, designed for use in refrigeration equipment to protect the system from too high discharge pressure. The KP pressure switch is also used to start and stop refrigeration compressors and air-cooled condenser fans. The reinforced contact group makes it possible to control the operation of electric motors without the use of contactors.
Characteristic:
Three-wire radiometric converter with an output of 0 - 5V and a measuring range of 0 - 34.5 Bar.
Power: 4.5÷5.5V DC. current
Output: 0.5÷4.5V DC current
Measuring range: PPR15 (0÷15bar) – PPR30 (0÷35bar).
Protection: IP65. Operating temperature: -40÷135°C (-40÷275°F).
Storage temperature: -40÷135°C (-40÷275°F).
Accuracy: 1.2% FS
Characteristic:
Three-wire radiometric converter with an output of 0 - 5V and a measuring range of 0 - 34.5 Bar.
Power: 4.5÷5.5V DC. current
Output: 0.5÷4.5V DC current
Measuring range: PPR15 (0÷15bar) – PPR30 (0÷35bar).
Protection: IP65. Operating temperature: -40÷135°C (-40÷275°F).
Storage temperature: -40÷135°C (-40÷275°F).
Accuracy: 1.2% FS
Product characteristics
Manufacturer | DIXELL |
Country of origin | Italy |
Источник | интернет-магазин запчастей https://magsbt.com/ |
