Code: 15682 | Art: SPD009SA
under the order
Characteristics
Manufacturer
—
Samsung
Country of origin
—
Italy
Model
—
Cod 734 DC97-00124B
Shaft length
—
127
Bushing for seal
—
25 mm
All characteristics
They buy with this product
The SAMSUNG crosspiece (Cod. 734 DC97-00124B) is the shaft on which the washing machine drum rotates. This part is necessary for the operation of moving structural elements. The bearing assembly, which is attached to the crosspiece, is responsible for the rotation of the drum. It is this part that holds the drum itself, so damage to it can lead to serious damage to the bearings, heating element, drum and tank as a whole. Therefore, it is important to diagnose the malfunction in time and fix the problem in order to prevent further breakdowns. The crosspieces in washing machines of different brands are similar to each other, but still have certain differences. Therefore, if it is necessary to replace the crosspiece, you need to select a suitable element, taking into account both the manufacturer and the model of the automatic machine.
Product characteristics
Manufacturer | Samsung |
Country of origin | Italy |
Model | Cod 734 DC97-00124B |
Shaft length | 127 |
Bushing for seal | 25 mm |
Seal size | 25x50,55x10/12 |
Bearing | 6203, 6204 |
Источник | интернет-магазин запчастей https://magsbt.com/ |
Collections
Applicability of the product to models of household appliances
Enter the first characters of the model in the search line below and the list will be filtered.
You can click on the model name to search for all spare parts for this model of equipment.
F1043GW/YLW F1043GWU/YLW F1045AGW/YLP F1045AGW/YLR F1045AGW/YLW F1045AGWU/YLW F1215JGW/YLP F1215JGW/YLW F1215JGWU/YLW F1245AVGW/YLE F1245AVGW/YLP F1245AVGW/YLR F1245AVGW1/XEH F1245AVGWU/YLW F611GW1/YLP F611GW1/YLW F611GW1U/YLW F611GWU/YLW F813JGB/YLP F813JGB/YLW F813JGB1/YLP F813JGE/YLP F813JGE/YLW F813JGE1/YLP F813JGP/YLP F813JGP1/YLP F813JGS/YLP F813JGS/YLW F813JGS1/YLP F813JGS1/YLW F813JGW/YLP F813JGW/YLW F813JGW1/YLP F813JGW1/YLW F813JGW1U/YLW F813JGWU/YLW F843GW/YLP F843GW/YLW F843GWU/YLW WF-F1054/YLP WF-F1054/YLR WF-F1054/YLW WF-F1054S/YLP WF-F1054S/YLR WF-F1054S/YLW
To place a wholesale order, you need to log in or register on the site, add the products you are interested in to the cart and send a request for prices.
Payment of an order in the online store is possible after agreeing with the manager. Make an order and he will contact you to coordinate payment methods.
