Code: 12005 | Art: 060-110166
under the order
Characteristics
Manufacturer
—
Danfoss
Country of origin
—
Denmark
They buy with this product
Danfoss KP 1 pressure switch - designed for use in refrigeration equipment to protect the system from too low suction pressure or too high discharge pressure. Also used for starting and stopping refrigeration compressors and air-cooled condenser fans. A reinforced contact group, designed for a load of 16 A, makes it possible to control the operation of electric motors with a power of up to 2 kW without the use of contactors.
Characteristic:
Max. test pressure - 20 bar.
Contact load, AC: AC1: 16 A, 400 V; AC3: 16 A, 400 V; AC15: 10A, 400V.
Max. starting current (LR): 112A, 400V.
Contact load, DC: DC13: 12 W, 220 V control current.
Characteristic:
Max. test pressure - 20 bar.
Contact load, AC: AC1: 16 A, 400 V; AC3: 16 A, 400 V; AC15: 10A, 400V.
Max. starting current (LR): 112A, 400V.
Contact load, DC: DC13: 12 W, 220 V control current.
Product characteristics
Manufacturer | Danfoss |
Country of origin | Denmark |
