Code: 18708 | Art: RC-U0530
under the order
Characteristics
Manufacturer
—
GIN-CHERN
Country of origin
—
China
They buy with this product
Receiver filter 2 X 9/16-18UNF O-Ring for fitting 9/16" G6 No. 6 Mini O-Ring AUGUST is a part of the refrigeration system that provides cleaning, accumulation of refrigerant and removal of moisture. It serves as an intermediate container where it collects and The refrigerant coming from the condenser is stored for a short time.
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Height: 200mm.
Cylinder height: 170mm.
Diameter: 60mm.
Volume: 480ml.
Inlet and outlet external thread: 9/16"-18UNF O-Ring, for fitting (August) G6, No. 6, nut thread 9/16"-18UNF Mini O-Ring.
Pressure sensor: 3/8"-24UNF.
External thread: 2 pcs.
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Height: 200mm.
Cylinder height: 170mm.
Diameter: 60mm.
Volume: 480ml.
Inlet and outlet external thread: 9/16"-18UNF O-Ring, for fitting (August) G6, No. 6, nut thread 9/16"-18UNF Mini O-Ring.
Pressure sensor: 3/8"-24UNF.
External thread: 2 pcs.
Product characteristics
Manufacturer | GIN-CHERN |
Country of origin | China |
Источник | интернет-магазин запчастей https://magsbt.com/ |
