Code: 18711 | Art: RC-U0505
under the order
Characteristics
Manufacturer
—
GIN-CHERN
Country of origin
—
China
Filter receiver 2 X 5/8 -18UNF Flare for fitting 3/8", G6, No. 6, O-Ring - this is a part of the refrigeration system that provides cleaning, accumulation of refrigerant and removal of moisture. It serves as an intermediate container where short-term The refrigerant coming from the condenser is stored for a while.
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Height: 150 mm.
Cylinder height: 120 mm.
Diameter: 76 mm.
Volume: 544 ml.
Inlet and outlet: external thread 5/8"-18UNF O-Ring, for fitting 3/8", G6, No. 6, O-Ring.
Pressure sensor: 3/8-24UNF.
External thread - 2 pcs.
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Height: 150 mm.
Cylinder height: 120 mm.
Diameter: 76 mm.
Volume: 544 ml.
Inlet and outlet: external thread 5/8"-18UNF O-Ring, for fitting 3/8", G6, No. 6, O-Ring.
Pressure sensor: 3/8-24UNF.
External thread - 2 pcs.
Product characteristics
Manufacturer | GIN-CHERN |
Country of origin | China |
