Code: 20159 | Art: RC-U0503
under the order
Characteristics
Manufacturer
—
GIN-CHERN
Country of origin
—
China
They buy with this product
Filter drier horizontal 238x177x63mm, volume 550 ml, 5/8"-18UNF O-Ring, for 3/8" fitting, G6 is a part of the refrigeration system that provides cleaning, accumulation of refrigerant and removal of moisture. It serves as an intermediate container where the refrigerant coming from the condenser is collected and stored for a short time.
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Model: RC-U0503.
Length: 238 mm.
Cylinder length: 177 mm.
Diameter: 63 mm.
Volume: 550 ml.
Gas inlet and outlet: external thread 5/8" 18UNF O-Ring, for fitting 3/8", G6, No. 6, O-Ring.
Pressure sensor: 3/8"-24UNF.
External thread: 1 piece
Located on the high pressure line, between the condenser outlet and the thermal expansion valve. The designs of the filter receiver are different, but in general it includes a container, a filtering adsorbent and a substance that removes moisture. There are models equipped with a sight glass, with which the refrigerant level and its condition are monitored.
Pressure sensors can be installed on the filter receiver housing.
Characteristic:
Model: RC-U0503.
Length: 238 mm.
Cylinder length: 177 mm.
Diameter: 63 mm.
Volume: 550 ml.
Gas inlet and outlet: external thread 5/8" 18UNF O-Ring, for fitting 3/8", G6, No. 6, O-Ring.
Pressure sensor: 3/8"-24UNF.
External thread: 1 piece
Product characteristics
Manufacturer | GIN-CHERN |
Country of origin | China |
