Code: 21448
under the order
Characteristics
Manufacturer
—
Danfoss
Country of origin
—
Denmark
The Danfoss 061F7526 ACB-2UA526W low pressure switch is a compact disk pressure switch with fixed settings for long-term use in refrigeration and air conditioning systems. It provides protection against automatic or manual limit reset. Its small size, lightness and high degree of protection allow it to be installed directly on refrigeration units. All these features reduce installation costs and save space.
Characteristic:
Burst pressure (psig): 2900 psig.
Burst pressure (bar): 200 bar.
Maximum ambient temperature range: 85 °C.
Minimum ambient temperature range: -30 °C.
Maximum ambient temperature range: 185°F.
Minimum ambient temperature range: -20°F.
Maximum operating temperature range: 135 °C.
Minimum operating temperature range: -55 °C.
Maximum operating temperature range: 275°F.
Minimum operating temperature range: -70°F.
Characteristic:
Burst pressure (psig): 2900 psig.
Burst pressure (bar): 200 bar.
Maximum ambient temperature range: 85 °C.
Minimum ambient temperature range: -30 °C.
Maximum ambient temperature range: 185°F.
Minimum ambient temperature range: -20°F.
Maximum operating temperature range: 135 °C.
Minimum operating temperature range: -55 °C.
Maximum operating temperature range: 275°F.
Minimum operating temperature range: -70°F.
Product characteristics
Manufacturer | Danfoss |
Country of origin | Denmark |
Источник | интернет-магазин запчастей https://magsbt.com/ |
