Code: 12378
under the order
Characteristics
Manufacturer
—
Danfoss
Country of origin
—
Slovakia
Model
—
EKS 211.
Number of contacts
—
2
Resistance
—
5
All characteristics
Temperature sensor 084B4403 Danfoss EKS 211 is a device that directly receives and converts the measured value into a signal for its subsequent transmission to devices or control action.
The sensor is designed to measure temperature in automatic monitoring, regulation and control systems of technological processes in various industries.
Resistance 5kOhm.
Thermocouple Thermal Sleeve Diameter (inches): 0.32 in.
Diameter of thermoelement protection sleeve: 8 mm.
Maximum temperature: 80 °C.
Minimum temperature: -40 °C.
Measuring range (max): 176 °F.
Measuring range (min.): -40 °F.
Cable temperature range (max): 100 °C.
Cable temperature range (min.) - 40 °C.
Thermocouple Thermal Length (inches): 1.18 in.
Length of thermoelement protection sleeve: 30 mm.
Cable Length (inches): 59.06 in.
Cable length: 1.5 meters.
Tolerance will be measured. sensor element: ± 5% (R) at 0°C.
The sensor is designed to measure temperature in automatic monitoring, regulation and control systems of technological processes in various industries.
Resistance 5kOhm.
Thermocouple Thermal Sleeve Diameter (inches): 0.32 in.
Diameter of thermoelement protection sleeve: 8 mm.
Maximum temperature: 80 °C.
Minimum temperature: -40 °C.
Measuring range (max): 176 °F.
Measuring range (min.): -40 °F.
Cable temperature range (max): 100 °C.
Cable temperature range (min.) - 40 °C.
Thermocouple Thermal Length (inches): 1.18 in.
Length of thermoelement protection sleeve: 30 mm.
Cable Length (inches): 59.06 in.
Cable length: 1.5 meters.
Tolerance will be measured. sensor element: ± 5% (R) at 0°C.
Product characteristics
Manufacturer | Danfoss |
Country of origin | Slovakia |
Model | EKS 211. |
Number of contacts | 2 |
Resistance | 5 |
Temperature range | -40 - 80°C |
Length, mm | 1500 |
Alternative article | 084B4403 |
Источник | интернет-магазин запчастей https://magsbt.com/ |
