Code: 14965 | Art: SPD014SA
under the order
Characteristics
Manufacturer
—
Samsung
Country of origin
—
Italy
Model
—
Cod 733 DC97-00124A
Shaft length
—
146.5
Bushing for seal
—
25 mm
All characteristics
They buy with this product
The SAMSUNG cross (Cod. 733 DC97-00124A) is the shaft on which the washing machine drum rotates. This part is necessary for the operation of moving structural elements. The bearing assembly, which is attached to the crosspiece, is responsible for the rotation of the drum. It is this part that holds the drum itself, so damage to it can lead to serious damage to the bearings, heating element, drum and tank as a whole. Therefore, it is important to diagnose the malfunction in time and fix the problem in order to prevent further breakdowns. The crosspieces in washing machines of different brands are similar to each other, but still have certain differences. Therefore, if it is necessary to replace the crosspiece, you need to select a suitable element, taking into account both the manufacturer and the model of the automatic machine.
Product characteristics
Manufacturer | Samsung |
Country of origin | Italy |
Model | Cod 733 DC97-00124A |
Shaft length | 146.5 |
Bushing for seal | 25 mm |
Seal size | 25x50,55x10/12 |
Bearing | 6203, 6204 |
Источник | интернет-магазин запчастей https://magsbt.com/ |
Collections
Applicability of the product to models of household appliances
Enter the first characters of the model in the search line below and the list will be filtered.
You can click on the model name to search for all spare parts for this model of equipment.
Samsung B815JGW/YLP Samsung B815JGW/YLW Samsung M601GW/YLW Samsung M601GW1/YLW Samsung M601GWE/YLR Samsung M801GW/YLW Samsung M801GW1/YLW Samsung M801GWE/YLR Samsung P6091GW/XEZ Samsung P6091GW/YLP Samsung P6091GW/YLR Samsung P6091GW/YLW Samsung P6091GW1/YLP Samsung P6091GWE/YLR Samsung P801DWN1/XAC Samsung P801GW/YLP Samsung P801GW/YLW Samsung P801GW1/YLP. Samsung P801GW1/YLW Samsung P801GWE/YLR Samsung P803JGW/YLP Samsung P803JGW/YLW Samsung P803JGW1/YLP Samsung P803JGW1/YLW Samsung P803JGWE/YLR Samsung P803JIW1/YLY Samsung P805JEW/XST Samsung P805JGW/YLP Samsung P805JGW1/YLP Samsung P805JGW1/YLW Samsung P805JGWE/YLR Samsung P8091EW/YLO Samsung P8091GW/XEP Samsung P8091GW/XEZ Samsung P8091GW/YLE Samsung P8091GW/YLP Samsung P8091GW/YLR Samsung P8091GW/YLW Samsung P8091GW1/YLP Samsung P8091GWE/YLR Samsung P843GW/YLP Samsung P843GW/YLW Samsung P853GW/YLE Samsung SWF-P10IW/YLR Samsung SWF-P10IW/YLW Samsung SWF-P10IWD/YLT Samsung SWF-P1201D/YLT Samsung SWF-P12IW/YLP Samsung SWF-P12IW/YLR Samsung SWF-P12IW/YLW Sa
To place a wholesale order, you need to log in or register on the site, add the products you are interested in to the cart and send a request for prices.
Payment of an order in the online store is possible after agreeing with the manager. Make an order and he will contact you to coordinate payment methods.
