SPD013SA, 301199 *Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12

*Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12 photo 1 -

*Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12 photo 2 -

*Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12 photo 3 -

*Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12 photo 4 -

Превью запчасти *Spider стиральной машины SAMSUNG Cod 732 DC97-00124D/11292A sleeveØ25мм H97мм bearing 203/204 oil seal25x50,55x10/12 photo 4 -

Code: 17297 | Art: SPD013SA, 301199

under the order

Characteristics

Manufacturer

—

Samsung

Country of origin

—

China

Model

—

Cod 732 DC97-00124D/11292A

Shaft length

—

Bushing for seal

—

25 mm

All characteristics

They buy with this product

The SAMSUNG crosspiece (DC97-00124D) is the shaft on which the washing machine drum rotates. This part is necessary for the operation of moving structural elements. The bearing assembly, which is attached to the crosspiece, is responsible for the rotation of the drum. It is this part that holds the drum itself, so damage to it can lead to serious damage to the bearings, heating element, drum and tank as a whole. Therefore, it is important to diagnose the malfunction in time and fix the problem in order to prevent further breakdowns. The crosspieces in washing machines of different brands are similar to each other, but still have certain differences. Therefore, if it is necessary to replace the crosspiece, you need to select a suitable element, taking into account both the manufacturer and the model of the automatic machine.

Product characteristics

Manufacturer	Samsung
Country of origin	China
Model	Cod 732 DC97-00124D/11292A
Shaft length	97
Bushing for seal	25 mm
Seal size	25x50,55x10/12
Bearing	6203, 6204
Alternative article	SPD013SA, 301199 ,
Источник	интернет-магазин запчастей https://magsbt.com/

Assessment 5, 29 votes

Collections

All spare parts SamsungSpare parts for washing machines SamsungAll drum spider Samsung

Applicability of the product to models of household appliances

Enter the first characters of the model in the search line below and the list will be filtered.
You can click on the model name to search for all spare parts for this model of equipment.

C1035AEW/XTL R1013JGWU/YLW R1015JGW/YLR R1015JGW/YLW R1015JGWU/YLW R1033GWC/YLP R1033GWC/YLW R1052GWSU/YLW R1213JGW/YLR R1213JGW/YLW R1215JGW/YLW R1215JGWU/YLW R1233GWC/YLP R1233GWC/YLW R1245AVGW/YLP R1245AVGW/YLR R1245AVGW/YLW R1245AVGWU/YLW R813JGWU/YLW R815JGW/YLR R815JGWU/YLW R852GWSU/YLW WF6522N7W/YLW WF6522S4V/YLR WF6522S4V/YLW WF6522S6V/YLP WF6522S6V/YLR WF6522S6V/YLW WF6522S7W/YLR WF6522S7W/YLW WF7522S6S/YLP WF7522S8C/YLP WF7522S8C/YLW WF7522S8R/YLP WF7522S8R/YLR WF7522S8R/YLW WF7522S9C/YLR WF7522S9C/YLW WF7522S9R/YLP WF7522S9R/YLR WF7522S9R/YLW WF7522SUV/YLP WF7522SUV/YLR WF7522SUV/YLW WF8522S9P/YLP WF8522S9P/YLW WF-R1254/YLR WF-R1254/YLW WF-R1256/YLP WF-R1256/YLW WF-R125AC/YLP WF-R125AC/YLR WF-R125AC/YLW WF-R125AV/YLP WF-R125NC/YLR WF-R125NC/YLW
