Code: 1906 | Art: 00000001906
under the order
Characteristics
Manufacturer
—
Eliwell
Country of origin
—
Italy
Model
—
ID 974
Number of sensors
—
2 sensors
Number of relays
—
3 relays
All characteristics
Similar products
Devices of the ID Plus 974 series are controllers with three digital outputs (relays), two temperature sensors (regulator and evaporator), one multifunctional input that can be used as a digital input or as a temperature sensor and one digital input connected to the TTL port of the device Operating temperature –5 … +55 °C Power supply 12 VDC/AC current (±10%) 50/60 Hz or 230 V AC current (±10%) 50/60 Hz Consumption Up to 4.5 W Analogue inputs 2 inputs NTC (original)/PTC/PT1000 (selectable by parameter H00 Digital input 2 voltage-free inputs (dry contact) Digital outputs 1 defrost relay: normal. open 8(4)A – normal. closed 6(3)A maximum 250 Vac current 1 Compressor relay: UL 60730 (A) 2 HP (12FLA - 72 LRA) 240V AC maximum current 1 Fan Relay: 5(2)A 250VAC maximum. current Housing Plastic PC+ABS UL94 V-0, polycarbonate glass, thermoplastic buttons Dimensions Front panel 74x32 mm, depth 59 mm. Terminals Screw terminals for cables up to 2.5 mm2
Product characteristics
Manufacturer | Eliwell |
Country of origin | Italy |
Model | ID 974 |
Number of sensors | 2 sensors |
Number of relays | 3 relays |
Relay power, A | 12 |
Block application method | Compressor control and refrigerator defrost control |
Источник | интернет-магазин запчастей https://magsbt.com/ |
Collections
To place a wholesale order, you need to log in or register on the site, add the products you are interested in to the cart and send a request for prices.
Payment of an order in the online store is possible after agreeing with the manager. Make an order and he will contact you to coordinate payment methods.
